P8300 Series Neoprene / EPDM / SBR Foam Tapes
Pres-On P8300 Series Neoprene / EPDM / SBR Closed Cell Foam Tapes are specification grade, firm density, black, closed cell Neoprene/EPDM/SBR blend tapes featuring a high-tack, rubber based, pressure sensitive adhesive (PSA) on one side with easy-to-use release liner.
Products Details
- Tech Specs
- Product Highlights
- Applications
- Available Options
| Standard Roll Sizes | Serial Number | Thinkness | Length |
|---|---|---|---|
| P8300 is 54 inches wide | P8306 | 1/16" | 100' |
| P8312 | 1/8" | 50' | |
| P8318 | 3/16" | 50' | |
| P8325 | 1/4" | 50' | |
| P8337 | 3/8" | 25' | |
| P8350 | 1/2" | 25' |
| Adhesion Properties | Test | Typical Performance | Test Method |
|---|---|---|---|
| High-tack pressure sensitive rubber based adhesive. One sided with release liner. | Loop Tack | 115 oz/in typical | TLM1 LIB1 |
| Adhesion to Steel @ 72°F | |||
| - Steel immediate | 7 lbs/inch width or foam tear | PSTC-1 | |
| - Steel after 24 hours | 8 lbs/inch width or foam tear | PSTC-1 | |
| Static Shear @ 72°F 1 x 1 x 500 grams | 1000 hours minimum | PSTC-7 | |
| Static Shear @ 72°F 1 x 1 x 1000 grams | 200 hours minimum | PSTC-7 | |
| Optimum Application Temperature | 50°F - 80°F | Pres-On PTM-2 | |
| Functional Temperature | 0°F - 140°F | Pres-On PTM-2 | |
| Shelf Life | 1 year stored at room temperature |
| Physical Properties | Property | Test Method | Units of Measure | Results |
|---|---|---|---|---|
| Density (PCF) | ASTM D1056 | lbs/ft2 | 9 ± 2 | |
| ASTM-D-1056-67 & 68, Grade # | -- | -- | SCE 43 | |
| ASTM-D-1056-91 & 07 SAE J18-R7/92 | -- | -- | 2C3 | |
| Compression Set (25% Max) | -- | Pass/Fail | Pass | |
| Compression Deflection (25%) | ASTM D1056 | PSI | 9 - 13 | |
| Water Absorption (by weight) | ASTM D1056 | % | 5 (10 allowed) | |
| Temperature Resistance | -- | F | -40F to +250F | |
| Elongation (Min) | ASTM D1056 | % | 150 | |
| Heat Aging (7 days @ 158°F, +30 max change) | -- | Pass/Fail | Pass | |
| Tensile Strength (Min) | ASTM D1056 | PSI | 100 | |
| Ozone (20% Stress 72hrs @ 100 PPHM) | ASTM-D-1171-94** | Pass/Fail | Pass | |
| Oil Resistance (7 days @ 74°F) | Fluid Emmersion E1 | Pass/Fail | Pass | |
| Flammability (UL 94 HF1, FMVSS302) | UL E208679 | Pass/Fail | Pass | |
| Flammability (Canada CAN/CSA C22.2#07-92) | UL E208679 | Pass/Fail | Pass | |
| UL 50, UL 50E, UL 157, UL 508 | UL JMLU2, MH10200 | Pass/Fail | Pass | |
| *For temperature resistance lower and or higher than the above figures, please contact customer service. Under certain conditions, values greater than -40/+250 are possible. |
- Absorb shock and dampen sound and vibrations
- Provide a tight, long-lasting seal against moisture, dust, and air leaks
- Pass FMVSS302, CAN/CSA C22.2 #017-92, and UL 94 HF1 for flammability
- Resist acids, alkali, ozone, and oxidation
P8300 Series Neoprene / EPDM / SBR Closed Cell Foam Tapes are general application tapes recommended for sealing roof curbs to A/C units, as well as sealing out rain, moisture, and dust. These watertight tapes also conform to irregular surfaces and are ideal for gasketing and weatherproofing windows and doors.
- Roof Curb
- Weather Stripping
- Door Gasketing
Application Notes
Ensure bonding surfaces are well unified, clean, dry and free of dirt and oils. Apply firm and even pressure to improve adhesive-to-surface contact. Allow proper temperature and time to enhance bond strength as adhesive flows onto the surface.
- Release Liner: Brown Kraft Paper
- Custom die-cut shapes
- Also available with acrylic pressure sensitive adhesive on one-side (minimums may apply)
