Technical data
High-density black polyurethane traction foam: a protective, cushioned, non-marring barrier with a high coefficient of friction that keeps its integrity even under extreme compression.
- High coefficient of friction; smooth, non-marring surface
- Resists abrasion; withstands heavy loads
- Flexible, conforms to irregular surfaces; easily die-cut
- Available with a single-side acrylic adhesive coating
Markets: Bumpers and footpads for business machines, industrial equipment, appliances, housewares and electronics
| Thickness | .062" standard (also .016", .030", .094", .125"; minimums apply) | |
|---|---|---|
| Hardness | 65 Shore O | ASTM D2240 |
| Density | 40 lb/ft³ (640 kg/m³) | ASTM D3574 |
| Tensile strength | 445 psi (3070 kPa) | ASTM D3574 |
| Coefficient of friction, kinetic | 1.4 | ASTM D4518 |
| Peel adhesion | 65 oz/in (7.2 N/cm); 180° peel 80 oz/in (8.8 N/cm) | PSTC-3 |
| Temperature resistance | Constant use max 158°F (70°C); intermittent max 250°F (121°C) |
| Log roll width | 54" | |
|---|---|---|
| Roll length | 100′ | |
| Die cuts | Custom shapes available |
Source: UR1700 data sheet (PDF). Values are typical unless stated. Color and finish may vary by lot; tolerances vary with thickness and width. Confirm suitability for your application with Pres-On.
